To predict the energy yield of residential solar PV fleets on the basis of limited information, Dutch researchers developed a probability-based mathematical model that offers calculations of Rapid Sky View factor (SVF), protects the privacy of PV factory owner and turned out to be effective for the study of PV-potentially
Research from the Netherlands’ Delft University of Technology (TU Delft) has resulted in a probabilistic framework to predict the energying of fleets of residential solar plants.
The new framework, which keeps the privacy of the individual plant owners, derives a probability of mass function (PMF) for access to sunlight. It contains shadow effects, sky view factor (SVF), light collective surface and diffuse sunlight on raw surfaces, while considering various parameters such as local slopes, lighting angle and height.
“We need fast PV yield forecast models for applications, such as PV design optimization, for real-time monitoring and error detection, and for making decisions on how to operate the grid. The solution was to integrate the roughness of urban morphology in PV-revenue,” Houtenbestywets, “Houtenbesty Movements,” Houten Saignity Movements, “Houten Saignity Assistance,” Houten Saignity Assistance, “Salidification of Salbality,” Salidification Movements, “Houten Saignery Movements,” Salidified Movements. told PV Magazine.
In the study, “Probability mass function of energy for light collecting surfaces in rough geometries and its applications in urban energy and photovoltaicPublished in the Ieee Journal of Photovoltaics, The need to include the roughness of the environment and light-collecting surface forms in PV calculations for residential solar energy was described as increasingly important because the adoption of solar PV in urban environments is increasing.
The Digital Surface Model (DSM) of Delft was used to develop the framework. “The DSM data are the altitude data of all objects on the earth’s surface,” said the researchers, and noted that the vegetation was removed using the QGIS software tool and the 3DEP Lidarexplorer portal of the US Geological Survey Science database was also used for Validatie and comparisons.
Two regions in Eindhoven were selected for the study: one in the city center and the other in the countryside. In each region, 50 PV systems were randomly selected and the energy yield of the two fleets was predicted using the mathematical framework and later compared to real measurements.
The only information of the available systems for the model was the aggregated installed capacity of each fleet, in particular 198.6 kW for the urban and 278.1 kW for the countryside. The exact installation place or orientation of the systems was unknown, which respected the privacy of the owners according to the researchers.
When the model was validated by comparing it with real, anonymized, PV system fleet data from regions in Eindhoven, which was provided by the Dutch software company Solar Monkey, the results showed that the predictions were in line with the earlier practical and simulated PV fleet data. “We now have a probability distribution function to predict the electricity output of the solar panel in urban areas,” said Ziar.
The new model reportedly avoids the need for time-consuming horizon scanning and SVF calculations to understand the shadow that influences the PV yield. According to Ziar, the yield calculation time was reduced from hours to seconds.
Providing information about aggregated PV electricity or fleet data, fits in with the way in which schedule operators use data in the scheduling node management, according to ZIAR. The use of data on fleet level also retains the privacy of PV owner. “Owners do not always want to share all the details about their systems, or they just don’t know. This model only needs limited and gross information about the PV systems,” he emphasized.
Looking ahead, ZIAR is planning to integrate the model with artificial intelligence -based techniques for expressions for irradiation. “So we will have a prediction of two levels, using machine learning first, we predict irradiation for a free horizon, after which we predict the PV fleet yield within an elevated horizon. Then we will work with grid operators to offer real-time PV-PV-return forecast for their decision-making process.”
Other areas that can benefit from such models, according to the researcher, Urban Heat Island Formation Studies, Sunlight Access Research for Citizens and Areas where there is need to quickly visualize a site using Sky View factor calculation.
