Nanyang Technological University researchers have glass solar panel waste for use in cathodes used in lithium metal batteries of a fixed state. When used as a functional filler in material with fixed polymer electrolyte (SPE), the resulting battery performance during 80 load cycles was maintained with an improvement of 8.3 % compared to the reference device.
A team of researchers from Nanyang Technological University in Singapore has developed a process to use glass panel waste as a raw material for cathodes in lithium metal batteries for fixed condition.
By milling broken solar glass waste in particles of nano format, they could process it for use as a functional inorganic filler in polyethylene oxide-based (PEO) fixed polymeer electrolyt (SPE) material. The resulting SPE showed improved electrochemical stability and ionic conductivity.
Batteries made with the SPE with 2 gain% glass nanoparticles retained a capacity of 123.07 mAh G⁻¹, which indicates an improvement of 8.3% compared to the reference.
To make the recycling of solar panels at the end of the lifespan (EOL) more attractive and more sustainable, researchers have investigated an upcycling, processing materials from the waste panel in high -quality products, while trying to prevent high temperature processes being avoided.
In one of the newest cases, Nanyang Technological University researchers in Singapore proposed to reuse glass in energy storage applications, and noted that it is the toughest EOL car component and that valuable upcycling applications are missing.
“Our research shows that solar glass of solar panels at the end of the lifetime has promising potential in the energy storage sector, in particular as a functional additive in fixed polymeer electrolytes (SPEs),” said corresponding author, Yeow Boon Tay, said PV Magazine, Add that conventional recycling methods for solar glass are often not energy-intensive and economically feasible.
“By reusing or upcycling of solar glass in functional nanom materials, this work promotes a more sustainable and circular approach, in which two fast -growing industries are linked – Solar Energy and Energy Storage,” said Boon Tay.
The research, which is being detailed in “Reusing solar Zonne waste for lithium metal batteries of a fixed condition“Published in Resources, preservation and recyclingDescribes the use of solar glass nanoparticles such as inerte, cost -effective and durable filling materials for use in Monster Lithium iron phosphate (LFP) cathodes (LFP)
SPE technology is seen as a “critical enabler” for the next generation of states batteries because of the improved safety and performance, according to Boon Tay.
“To insulate the solar glass of the PV, solvent for weeks and the cutting of wire were used to insulate the glass, so that energy-intensive thermal methods are usually used to remove the ethylene vinylacetate (EVA) inkhadowing,” the team said. It then used a ball -free process to mill the broken glass without using toxic chemicals to around 300 Nm. These nanoparticles were then included as a filler in a polyethylene oxide-based (PEO), a commonly used SPE, according to the research.
“Our approach uses a simple and direct physical method to convert waste of solar glasses into nanoparticles, avoiding chemical-intensive synthesis routes. This makes the process considerably more cost-effective and less energy-intensive compared to traditional methods for the producing glass, moreover, the use of it is the use of the use of the usage of the use of it, moreover, the use of the use of filling materials. Carbon footprint, by increasing the durability profile, “that it is used by the raw material.
The group discovered that the spe, modified by the glass, showed an increased electrochemical stability and an improved ionic conductivity. “Specific, the ionic conductivity of pure peo with litfsi (lithium salt) spe, measured at 9.66 x 10⁻⁶ s/cm at room temperature, raised to 1.10 x 10⁻⁵ s/cm after adding 2 WT % glass nano particles,” it said.
Lithium metal batteries were made with the resulting SPE and evaluated for performance by the researchers. The results showed superior bicycle stability for SPEs that contain glasses of nanoparticles. After 80 cycles, the specific capacity of the reference dropped to 113.60 mAh g⁻¹, while the sample with 2 wage. % Glass nanoparticles retained a capacity of 123.07 mAh G⁻¹, indicating an improvement of 8.3 %.
“These findings emphasize the potential of redesigning glass waste from solar panels in functional nanom materials for SPE applications,” they concluded.
Asked about what the next step is for the research team, Boon Tay stated that the development of methods with a low impact to restore high -quality materials and reuse solar panels at the end of life is the focus, in particular energy storage applications. “After this study, we also developed low temperature processes to update silicon in lithium-ion battery anodes, to support a more circular and sustainable ecosystem for renewable energy,” said Boon Tay.
This content is protected by copyright and may not be reused. If you want to work with us and reuse part of our content, please contact: editors@pv-magazine.com.
